High-Efficiency Intelligent Switchgear Dehumidifier for Panels

Introducing the LYCS-DP120 Dehumidifier – a cutting-edge solution tailored for safeguarding switch cabinets. Designed to combat moisture-related issues, this high-performance device ensures optimal conditions for sensitive equipment. With advanced technology and a compact build, it seamlessly integrates into diverse environments, guaranteeing efficient moisture control.

Quantity:
Availability:





Inquire Add to Basket

Switchgear Dehumidifiers LYCS-DP120 Switch cabinet dehumidifier Energy-Efficient Dehumidification Electrical Equipment Protection Commercial Dehumidifiers

Product Introduction

Product Features

Technical Parameters

Applications

FAQ

Product Overview

In power distribution and industrial electrical systems, moisture accumulation inside switchgear cabinets is a silent but destructive threat. It causes metal corrosion, insulation degradation, and short circuits, leading to unplanned downtime, costly repairs, and even safety hazards. The LYCS-DP120 switchgear dehumidifier is a purpose-built solution engineered to eliminate these risks by maintaining a dry and stable environment within electrical enclosures.

This cabinet dehumidifier for electrical equipment integrates advanced mechatronic technology with intelligent control systems, delivering reliable moisture removal for switchgear cabinets ranging from 1 to 3 cubic meters. Its compact design allows seamless installation in both new and existing setups without interfering with internal components, making it an essential addition to any critical electrical infrastructure. By keeping relative humidity below 50% RH, it extends equipment lifespan, reduces maintenance costs, and enhances the overall reliability of power distribution networks.

High-Efficiency Intelligent Switchgear Dehumidifier for Panels

Product Advantages

High-Efficiency Dehumidification Performance

Equipped with a powerful dehumidification module, this industrial dehumidifier for switch cabinets achieves a moisture removal rate of 850ml per day under standard conditions (35℃, 85% RH). It rapidly extracts excess moisture from the air, preventing condensation formation on busbars, circuit breakers, and other sensitive electrical parts that are prone to malfunctions when exposed to dampness.

Intelligent Automatic Control System

The device features a high-accuracy humidity and temperature sensor that continuously monitors cabinet conditions. Once humidity exceeds the user-set threshold (adjustable from 45% RH to 98% RH), the dehumidifier activates automatically. It shuts off when the desired humidity level is reached, optimizing energy usage and ensuring consistent performance without manual intervention.

Compact and Space-Saving Design

Recognizing the limited space inside switchgear cabinets, this compact cabinet dehumidifier measures only 330×215×280mm (width×depth×height). Its wall-mounted fixed installation method saves valuable internal space, making it compatible with all standard switchgear models and ideal for retrofit projects.

Durable Construction for Harsh Environments

Built with corrosion-resistant sheet metal casing, the dehumidifier withstands dust, moisture, and temperature fluctuations common in industrial and utility settings. Its high-quality internal components ensure long-term reliable operation, even in continuous use scenarios.

Low Power Consumption

Designed with energy efficiency in mind, this energy-efficient switchgear dehumidifier offers multiple dehumidification power options (60W, 80W, 100W, 120W) to match different cabinet sizes and humidity levels. This not only reduces operational energy costs but also aligns with sustainable business practices.

Technical Specifications

Name	LYCS-DP120
Working power supply	110~254VAC、127~370VDC
Dehumidification efficiency	850ml/day(Under working conditions60W 35℃ 85%RH)
heating power	50-500W
Dehumidification temperature	5℃-45℃
Dehumidification power	60W,80W,100W,120W
Operating temperature	0℃-50℃
Humidity detection range	20%RH-98%RH
Temperature detection range	-25℃-125℃
Dehumidification start value	45%RH-98%RH
Temperature start value	1℃-55℃
Humidity measurement accuracy	±3%RH
Temperature measurement accuracy	±1℃
Display method	Double row 3 digital display
display resolution	0.1
shell material	sheet metal
Dimensions	330✖215✖280mm(Width✖depth✖height)
Size of the opening	Wall-mounted (Fixed)
Dehumidification volume	1-3m³
aqueduct	Silica gel D10mm、L1.5m
Remote monitoring background	Optional

Applications

Power Generation Stations: Protects switchgear in thermal, hydro, and renewable energy plants, preventing power outages caused by moisture-related equipment failures.

Electrical Substations: Maintains dry conditions in distribution and transmission substations, safeguarding busbars, transformers, and circuit breakers from corrosion and insulation damage.

Industrial Facilities: Ideal for manufacturing plants, chemical processing facilities, and mining operations where harsh and humid environments pose significant risks to electrical equipment.

Commercial Buildings: Ensures reliable operation of switchgear in office buildings, shopping malls, and hospitals, preventing electrical hazards and service disruptions.

Selection Guide

Cabinet Volume: Choose the LYCS-DP120 for switchgear cabinets with a volume of 1-3 cubic meters. For larger cabinets, consider multiple units or higher-capacity models.

Environmental Conditions: If the installation location experiences high humidity (above 80% RH) or extreme temperatures, select a higher dehumidification power option (100W or 120W).

Power Supply: Verify the available power source (AC or DC) and ensure it matches the device's input range (110-254VAC or 127-370VDC).

Remote Monitoring Needs: If centralized monitoring is required, opt for the optional remote monitoring background feature for real-time status tracking and alerts.

Operation Guide

Installation: Mount the dehumidifier on the inner wall of the switchgear cabinet using the provided brackets, ensuring it is securely fixed and not obstructing air circulation.

Drainage Setup: Connect the included silica gel drainage tube to the device and route it to an external drainage point to prevent water accumulation inside the cabinet.

Parameter Setting: Use the control panel buttons to set the desired humidity threshold (recommended 45-50% RH) and temperature parameters. The device will automatically start dehumidification when conditions exceed the set values.

Maintenance: Periodically inspect the drainage tube for blockages and clean the air intake filter to ensure optimal performance. Check the sensor calibration annually for accurate readings.
