Combined American-style Packaged Substation

Low No-load Loss Combined American-style Packaged Substation for Industrial Power Systems

The Low No-load Loss Combined American-style Packaged Substation is designed for industrial power systems, offering a compact and efficient solution for reliable power distribution. Integrating key components such as the transformer core, high-voltage load switch, and fuse within the transformer oil tank, this substation ensures a reliable power supply with minimal operational downtime.

Quantity:
Availability:





Inquire Add to Basket

Power Transformer Combined American Type Transformer Substation Prefabricated Substation Distribution Transformer Manufacturer Industrial Power Transformer

Product Feastures

Model Specifications

Application

Why Choose Us?

FAQs

Product Feastures

Compact Integrated Design: The Combined American-style Packaged Substation integrates the transformer core, high-voltage load switch, and fuse into a single, compact unit, offering a streamlined solution for installation and operation. This design minimizes space requirements and simplifies the setup process, making it highly efficient for industrial environments with limited space.
High-Quality Transformer Core: The transformer core is constructed using premium low-loss, high-permeability cold-rolled grain-oriented silicon steel sheets. These materials are chosen for their excellent magnetic properties, which reduce energy loss and enhance operational efficiency. The core’s low magnetic density minimizes heat generation and contributes to better overall performance. This ensures that the substation operates efficiently, with lower energy consumption and improved load handling.
Noise Reduction Technology: Designed with noise reduction in mind, the substation’s transformer core is engineered to reduce operational noise. The cold-rolled grain-oriented steel sheets not only improve efficiency but also minimize the noise produced during operation. This makes the substation ideal for environments where low noise levels are critical, such as in urban or residential areas, or near sensitive equipment.
Superior Coil Conductors: The substation utilizes oxygen-free copper for its coil conductors, ensuring exceptional conductivity and long-lasting durability. Oxygen-free copper enhances the overall reliability of the substation, as it resists corrosion and degradation over time, providing a stable power supply with minimal maintenance.

Low No-load Loss Combined American-style Packaged Substation for Industrial Power Systems

Advanced Drying System: To ensure optimal performance, the substation employs an advanced drying system that guarantees effective moisture removal during manufacturing. This drying process helps prevent insulation failures and prolongs the life of the transformer, ensuring that it operates efficiently under diverse environmental conditions and temperature fluctuations.
Low No-load Loss Design: The substation’s low no-load loss design is a key feature that contributes to significant energy savings. By reducing energy wastage when the system is idle, this design lowers operational costs and minimizes environmental impact. It ensures that the substation operates in the most energy-efficient manner possible, making it a cost-effective solution for long-term power distribution needs.
Energy Efficiency and Cost Reduction: The combination of a high-efficiency transformer core, oxygen-free copper coils, and a low no-load loss design reduces operational costs and increases the energy efficiency of the system. This makes the substation a highly cost-effective investment, ensuring reliable power delivery while minimizing the total cost of ownership over its lifecycle.

Model Specifications

Parameter	Specification
Operating Conditions	Outdoor installation
Model	ZGS series
Capacity	630 to 4000 kVA
Rated Voltage	High voltage: 37kV; Low voltage: 0.6kV
Impedance	6% - 8%
Insulation Class	Class A
Connection Group	Dy11
Insulation Level	LI200AC85/AC5
Execution Standards	GB/T 6451-2015, GB/T 1094.3-2017

American-style Packaged Substation

Application

Industrial Power Systems: Designed specifically for industrial environments where space is often limited, the Low No-load Loss Combined American-style Packaged Substation provides a compact yet highly efficient solution for power distribution. Its robust design ensures reliable operation under demanding conditions, making it the perfect choice for industries that require consistent, efficient, and uninterrupted power supply for their operations.
Ring Network and Terminal Power Supply: This substation is highly adaptable, making it suitable for both ring network and terminal power supply systems. Its dual compatibility allows for flexible deployment in various industrial settings, ensuring optimal power distribution regardless of the specific power supply architecture. Whether supporting a closed loop or a radial network, this solution ensures reliable power flow and enhances system resilience.
Outdoor Power Distribution: Engineered for use in outdoor environments, the substation is built to withstand harsh weather and environmental conditions. It maintains high performance even in extreme temperatures, humidity, and exposure to the elements, ensuring continuous and safe power distribution. This makes it ideal for applications in remote locations, construction sites, or outdoor industrial complexes where protection against environmental challenges is critical.

Why Choose Us?

Decades of Experience: Over 20 years of expertise in designing, manufacturing, and supporting advanced power solutions.
Expert Engineers and Specialists: Our team consists of skilled engineers and technical specialists with deep expertise in power transformer technologies.
Cutting-edge Designs: Focused on energy-efficient solutions and industrial power systems, using the latest technology.
High-quality Materials and Technologies: We select premium materials and employ state-of-the-art manufacturing technologies, including fully automated production lines and advanced drying systems.
Precision and Reliability: Our production processes ensure that each product is made with precision, reliability, and efficiency.
Research and Development Commitment: A continuous commitment to R\&D allows us to remain at the forefront of industry trends, providing tailored solutions that meet specific customer needs.
Wide Industry Applications: Trusted partners for sectors like rail transit, urban infrastructure, and industrial power systems.
Innovation and Customer Support: By prioritizing innovation, quality control, and customer support, we deliver high-performance power solutions that distinguish us from competitors.

In summary, at Hangzhou Liyi Electric Co., Ltd., our decades of experience, commitment to innovation, and unwavering focus on quality ensure that we deliver reliable and high-performance power solutions tailored to meet the unique needs of each customer. Trust us to be your partner in powering a sustainable and efficient future.

FAQ

Q1: What are the benefits of the low no-load loss design?
A1: The Low No-load Loss Combined American-style Packaged Substation reduces energy consumption, resulting in significant energy savings and lower operational costs while maintaining reliable power supply.

Q2: How does the transformer core reduce noise?
A3: The transformer core is made from high-permeability cold-rolled grain-oriented silicon steel sheets with laser scribing, which minimizes noise by maintaining low magnetic density.

Q3: What makes this substation energy-efficient?
A4: The Combined American-style Packaged Substation features low no-load loss and high efficiency in the transformer core design, significantly reducing energy wastage during operation.
